221-75176-01_B

221-75176-01_B

10F-AOC5-8/0.47C

Part Number: 221-75176

Login to view price

OUT OF STOCK

CHECK AVAILABILITY

Compare

Type: Fixed Needle Syringe

Needle Tip Style: Cone

PTFE Tipped Plunger: No

Needle Length (mm): 80

Needle Gauge: 26

Needle OD (mm): 0.47

Needle ID (mm): 0.11

Usage: AOC-5000 Plus

Syringe Volume: 10 μL

Needle Length (): 80

Lead Time: 3 - 5 weeks

Syringe Volume	PTFE Tipped Plunger	Needle Length (mm)	Needle Gauge	Needle OD (mm)	Needle ID (mm)	Needle Tip	P/N
10 μL	−	50	26	0.47	0.11	Cone	221-75175
10 μL	−	50	23	0.63	0.11	Cone	221-75175-01
10 μL	−	80	26	0.47	0.11	Cone	221-75176
10 μL	−	80	23	0.63	0.11	Cone	221-75176-01
10 μL	√	50	26	0.47	0.11	Cone	221-75175-02
10 μL	√	50	23	0.63	0.11	Cone	221-75175-03
25 μL	√	50	23	0.63	0.24	Cone	221-75177
1 mL	√	50	26	0.47	0.15	Side Hole Dome	221-75178
1 mL	√	50	23	0.63	0.15	Side Hole Dome	221-75178-01
2.5 mL	√	50	26	0.47	0.15	Side Hole Dome	221-75179
2.5 mL	√	50	23	0.63	0.15	Side Hole Dome	221-75179-01
